  • Model #:PK-888
  • Name:PANTESTER PRO
more big imgs
  • https://pansco.com/cache/20111014175907_cut.252.206.jpg

PANTESTER PRO - Universal Cable Tester



PK-102PL: Remote includes PoE & POTS service detector.

PK-102K: includes PK-102, #1 - #8 test & ID remotes and Net Probe



PANTESTER PRO is an advanced pin to pin tester to identify wiring faults in voice, data network, video/security/media, PC-USB 2.0/3.0. Mini B, Firewire 1394 4/6/9 pins cables and any custom configuration assembly cables with no need for adapters. We’ve made PANTESTER PRO a more cost effective solution, providing an all inclusive device that is capable of a “quick check” test and learning mode for testing large quantity of custom cables and pin to pin mode for checking actual pin configuration of 1-10 pins cables. You can either step through the test cables wiring or have the tester automatically check and display the result on the main unit. Two sets of LED bars for source and test indication. Other features includes pass, fail and low battery indicators. The main unit includes a storage area in the base to hold the remote unit, this allows to do easy loopback testing on patch cables. Remove the remote unit for testing installed cable to over 300m (1000ft). PANTEST PRO designed to aid network IT installation and maintenance personal and computer stores in the quick and easy verification of all kind of cables in one unit.



  1. Includes complete interface (RJ45, RJ11/12, BNC, F, RCA, USB2.0/3.0, Mini B and 1394 4/6/9pins) with no need for adapters.
  2. Checks actual pin to pin configuration of 1-10 pin cables.
  3. Display test result TX/RX on the main unit on remote testing.
  4. Test and troubleshoot wiring to over 300m.
  5. Includes Fast Check, Learning and pin by pin test modes.
  6. Learning function allows testing any custom configuration in any quantity a snap.
  7. Includes Pass, Fail and Battery low indicates.
  8. It also features convenient Auto scan and precision manual scanning mode.





1. Cable Tested

Standard and any custom configuration cable.

STP, UTP, USOC 2/4/8/6, COAX BNC/F, RCA, USB 2.0/3.0, MINI B and 1394 4/6/9pins

2. Test Mode

Fast test, Learning and Pin to Pin testing

3. Test Performed

Tests for open short miswire, crossover, reversed, pass/fail, shield, max length over to 300m

4. Battery

One 9V alkaline battery

5. Operating  Temp.

0°C - 45°C  (32°F -113°F)

6. Size/Weight

Main:

Remote:

Combined:

7. Display

 TX/RX Light Bar

8. Certification and compliance

CE Approved

RoHS Compliant
